Hinge Pin Clearance . pin hinges, also known as pivot hinges, are mechanical bearings that connect two solid objects, allowing a limited angle of rotation between. to design a free fit hinge, first establish maximum hole size in the retaining component (tight fit). But regardless of the type of pin, engineers should minimize the gap between hinged components to reduce clearance and avoid bending. after lots of experimentation, i found that a 0.5mm clearance radially around the hinge pin (.25mm offset) and 0.5mm (.25mm on each side) of vertical. offset hinges are designed to add extra clearance to doorways. understanding shaft and hole clearance to interference fits, how to determine fit, and specifying a fit in mechanical system design
